Carburization Resistance Inconel 617 Rod High Temperature Strength Oxidation

Products

Carburization Resistance Inconel 617 Rod High Temperature Strength Oxidation

MOQ:	150kgs
Price:	Negotiatable
Standard Packaging:	Wooden Case Packaging
Delivery Period:	2-30days
Payment Method:	L/C,T/T,Western Union,MoneyGram
Supply Capacity:	300 Ton per Month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

NikTech

Certification

ISO 9001:2008

Model Number

Inconel 617

Place Of Origin:

China

Us No:

UNS N04404

Form:

MIG(15kg/spool), TIG(5kg/box),Strip

Special Use:

Compressor Disks,machine Manufacturing

Grade:

Nc050

Business Type:

Manufaturer

Width:

1500mm

Applications:

Marine And Chemical Processing Equipment, Oil And Gas Industry, Aerospace Components

Alloy:

Nickel Copper Alloy

Quality Test:

MTC (mill Test Certification)

Elongation:

35-50%

Modulus Of Elasticity:

207 GPa

Brand No:

Uns No4400 2.4360 / NA 12 / Nu30

Yield Strength:

790 MPa

Packing:

Wooden Case Packaging

Highlight:

Carburization Resistance Inconel Alloy

Strength Oxidation Inconel Alloy

N04404 inconel 617 rod

Product Description

Inconel 617 Rods: High-Temperature Strength and Oxidation and Carburization Resistance

Product Overview

Inconel 617 Rods (UNS N06617/W. Nr. 2.4663a) are precision-forged, solid-solution-hardened nickel-chromium-cobalt-molybdenum bars designed for extreme high-temperature and corrosive conditions. The alloy’s unique formulation—nominally 52 % nickel, 22 % chromium, 12.5 % cobalt, 9.5 % molybdenum, 1.0 % aluminum, and 0.3 % titanium—delivers tensile strengths above 760 MPa and yield strengths around 310 MPa after solution annealing at 982 °C, while maintaining elongation of at least 30 %. This solid-solution strengthening mechanism provides stable mechanical properties without the need for precipitation aging, ensuring consistent performance over long service lives. The high chromium and aluminum content forms a continuous chromia–alumina scale, granting superior oxidation and carburization resistance in both oxidizing and reducing atmospheres, including high-purity water and steam environments. Excellent weldability—via TIG/GTAW or electron-beam—and formability support fabrication of rods, pins, and complex shapes for gas turbines (combustor liners, transition ducts), chemical reactors (coils, agitation shafts), furnace components (radiant tubes, thermocouple sleeves), and nuclear hardware (control-rod stems, spacer pins).

Chemical Composition

Element	Content (%)
Nickel (Ni)	50.0 – 55.0
Chromium (Cr)	20.0 – 24.0
Cobalt (Co)	12.0 – 15.0
Molybdenum (Mo)	8.0 – 10.0
Aluminum (Al)	0.4 – 1.0
Titanium (Ti)	0.2 – 0.6
Iron (Fe)	Balance
Carbon (C)	≤ 0.10
Manganese (Mn)	≤ 1.0
Silicon (Si)	≤ 0.50
Phosphorus (P)	≤ 0.015
Sulfur (S)	≤ 0.015

Mechanical Properties

Condition	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)	Hardness
Solution Annealed	≥ 760	≥ 310	≥ 30	≤ 95 HRB
Cold-Drawn	~ 758	~ 383	~ 56	~ 193 BHN

Physical Properties

Property	Value
Density	8.19 g/cm³
Melting Range	1330 – 1380 °C
Thermal Conductivity (25 °C)	11.1 W/m·K
Specific Heat (25 °C)	435 J/kg·K
Coefficient of Thermal Expansion (20–100 °C)	13.0 µm/m·°C
Electrical Resistivity (25 °C)	1.27 µΩ·m
Magnetic Permeability	≈ 1.002

Conformance Standards

ASTM B166 / B168 – Cold-drawn and hot-rolled rods
AMS 5520 – Special form, bar and rod
ISO 15156-3 / NACE MR0175-3 – Materials for sour-gas environments
UNS N06617 / W. Nr. 2.4663a – Alloy designation

Applications

Gas Turbines: Combustor liners, transition ducts, turbine blades
Chemical Processing: Reactor coils, agitator shafts, piping
Furnace Equipment: Radiant tubes, heat-treat baskets, thermocouple protection
Nuclear: Control-rod stems, spacer pins, support rods
Marine: Seawater valves, heat-exchanger tubes, desalination hardware

Frequently Asked Questions

Q1: Why select Inconel 617 Rods for high-temperature service?
A1: Their solid-solution strengthening maintains tensile strength and ductility up to 982 °C, plus superior oxidation and carburization resistance .

Q2: Are Inconel 617 Rods weldable without degradation?
A2: Yes—TIG/GTAW and electron-beam welding produce sound joints; solution annealing post-weld restores full mechanical and corrosion resistance .

Q3: What diameters and finishes are available?
A3: Diameters from 3 mm to 200 mm, standard lengths to 6 m; mill-annealed, annealed & pickled, or stress-relieved per ASTM B166/B168 .
