ASTM JIS AISI EN GB Monel K500 Rod Corrosion Resistance
  • name

ASTM JIS AISI EN GB Monel K500 Rod Corrosion Resistance

MOQ: 150kgs
Price: Negotiatable
Standard Packaging: carton, plywood pallet
Delivery Period: 2-30days
Payment Method: L/C,T/T,Western Union
Supply Capacity: 300 Ton per Month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
NikTech
Certification
ISO 9001:2008
Model Number
Monel K500
Surface Treatment:
Copper Coated
Alloy:
Nickel Copper Alloy
Thermal Stability:
Excellent
Nickel Composition:
52~57%
Testing Facility:
Accept Third Party Testing Such As SGS
Thermal Conductivity:
21.8 W/mK
Standard:
ASTM, JIS, AISI, EN, GB
Condition:
Hard / Soft
Elongation:
35-55%
Width:
As Your Request
Application:
Anti-corrosion
Grade:
Monel K-500, Monel400
Chemical Position:
Ni 63%min; Cu 28-34%
Type Of Material:
Nickel-copper Alloys
Highlight:

GB monel k500 rod

,

AISI monel k500 rod

,

Corrosion Resistance k500 round bar

Product Description

Monel K500 Rod – Superior Corrosion Resistance & High Mechanical Strength for Marine, Petrochemical & Aerospace Systems



Description

Monel K500 rod is a precipitation-hardened nickel-copper alloy designed to deliver exceptional corrosion resistance, high tensile strength, and durability in the most aggressive industrial environments. Composed of 63–67% nickel, 27–33% copper, with additions of aluminum (2.3–3.15%) and titanium (0.35–0.85%), this alloy combines the corrosion resistance of Monel 400 with enhanced mechanical properties through γ' phase (Ni₃(Al,Ti)) precipitation hardening.

Ideal for marine, oil & gas, and aerospace applications, Monel K500 rods achieve a tensile strength of 1,100–1,300 MPa and yield strength of 800–1,000 MPa after aging treatment, outperforming conventional stainless steels in high-stress and corrosive conditions. Its resistance to chloride-induced pitting, stress corrosion cracking (SCC), and sulfidation in H₂S-rich environments makes it indispensable for subsea components, sour gas well tools, and seawater pump shafts. With a melting range of 1,288–1,343°C and near-zero magnetic permeability even at cryogenic temperatures (-196°C), it ensures reliability in extreme thermal, chemical, and electromagnetic conditions.

Technical Specifications (Table)

Property Value Standard
Chemical Composition Ni: 63–67%, Cu: 27–33%, Al: 2.3–3.15% ASTM B865, ASME SB-127
  Ti: 0.35–0.85%, Fe: ≤2.0%, Mn: ≤1.5% NACE MR0175, DIN 17752
Mechanical Properties Tensile Strength: 1,100–1,300 MPa ASTM B865, ISO 15156-3
  Yield Strength: 800–1,000 MPa
  Elongation: ≥20%
Physical Parameters Density: 8.80 g/cm³ ISO 6892
  Melting Point: 1,288–1,343°C
  Thermal Conductivity: 22 W/m·K

Applications

  1. Marine Engineering: Propeller shafts, seawater valve stems, and offshore platform fasteners.

  2. Oil & Gas: Downhole drilling tools, valve trim, and H₂S-resistant pipeline components.

  3. Aerospace: High-strength fasteners, turbine blades, and engine components.

  4. Chemical Processing: Reactor agitators, heat exchanger tubes, and sulfuric acid handling systems.

  5. Nuclear Energy: Control rod drive mechanisms and radiation-resistant instrumentation.

Q&A

Q1: How does Monel K500 compare to Monel 400 in mechanical performance?
A: Monel K500 offers 3x higher yield strength and 2x higher tensile strength due to aluminum/titanium additions and aging treatment, while maintaining equivalent corrosion resistance.

Q2: Can Monel K500 rods withstand cryogenic temperatures?
A: Yes. The alloy retains ductility and near-zero magnetic permeability at -196°C, ideal for LNG storage and superconducting applications.

Q3: What heat treatment is required for optimal performance?
A: Aging at 593–607°C for 6–16 hours followed by controlled cooling maximizes γ' phase precipitation. Stress relief annealing at 620–650°C is recommended for cold-worked rods.

Tags:

monel 400 bar,

Monel Alloy,

monel round bar
