Monel K 500 Supper Nickel Copper Alloy UNS N05500 Bright Polished

Products

Monel K 500 Supper Nickel Copper Alloy UNS N05500 Bright Polished

MOQ:	150kgs
Price:	Negotiatable
Standard Packaging:	Wood box for Rod
Delivery Period:	2-30days
Payment Method:	,L/C,T/T,Western Union,MoneyGram
Supply Capacity:	300 Ton per Month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

NikTech

Certification

ISO 9001:2008

Model Number

Monel 400

Condition:

Hard / Soft

Melting Range:

1315-1350

Alloys:

Copper Nickel Alloys

Alloy Type:

Nickel-cu-al Alloy

Alloy Or Not:

Is Alloy

Alloy:

Nickel Copper Alloy

Equal Grade:

UNS N05500

Size:

Customized

Electrical Resistivity:

0.615 µΩ·m (at 20°C)

Machinability:

Type Of Tube:

Straight Tube, U Bend Tube , Coil Tube

Place Of Orig:

China

Modulus Of Elasticity:

200 GPa (29 × 10^6 Psi)

Surface:

Bright,Polished,black

Grade:

UNS N05500/ W.Nr. 2.4375

Highlight:

Bright nickel copper alloy

N05500 nickel copper alloy

Polished monel k 500

Product Description

Monel K-500 supper nickel copper alloy

Monel K-500 is a nickel-copper alloy that combines the excellent corrosion resistance of Monel 400 with enhanced strength and hardness. This improvement is achieved through the addition of aluminum and titanium, followed by age hardening, which precipitates submicroscopic particles throughout the matrix.

Chemical Composition For Monel K500:

Element	Percentage (%)
Nickel (plus Cobalt)	63.0 min
Copper	27.0 - 33.0
Aluminum	2.30 - 3.15
Titanium	0.35 - 0.85
Iron	2.0 max
Manganese	1.5 max
Silicon	0.5 max
Carbon	0.25 max
Sulfur	0.01 max

Physical Properties Of Monel K500

Property	Value
Density	8.44 g/cm³
Melting Range	1315-1350°C
Modulus of Elasticity	179 GPa (tension)
Electrical Resistivity	6.15 μΩ·m at 20°C
Thermal Conductivity	17.2 W/m·K at 20°C

Mechanical Properties Of Monel K500:

Condition	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)	Hardness (HRC)
Hot-Finished, Aged	965 - 1310	690 - 1035	30 - 20	27 - 38
Cold-Drawn, Aged	930 - 1275	655 - 1100	30 - 15	25 - 41

Key Characteristics:

Corrosion Resistance: Monel K-500 exhibits excellent resistance in various marine and chemical environments, from pure water to non-oxidizing mineral acids, salts, and alkalis.
High Strength and Hardness: The alloy maintains high mechanical properties from sub-zero temperatures up to approximately 480°C.
Low Magnetic Permeability: In the age-hardened condition, Monel K-500 has low permeability and is non-magnetic to temperatures as low as -101°C.

Applications:

Monel K-500 is utilized in various industries due to its unique properties:

Marine Engineering: Ideal for chains, cables, springs, and valve components due to its corrosion resistance and high strength.
Oil and Gas Production: Used in pump shafts, impellers, and non-magnetic housings, benefiting from its resistance to sour-gas environments.
Chemical Processing: Suitable for pump and valve components, offering durability in harsh chemical environments.
Aerospace and Defense: Employed in manufacturing turbine blades and gas turbine components operating below 750°C.

When considering Monel K-500 for high-temperature industrial applications, it's essential to compare its properties with Monel 400. While both alloys offer excellent corrosion resistance, Monel K-500 provides superior mechanical strength and hardness, making it more suitable for demanding environments. However, Monel K-500 may have a greater tendency toward stress-corrosion cracking in certain conditions compared to Monel 400.

In summary, Monel K-500's combination of corrosion resistance, high strength, and low magnetic permeability makes it a preferred choice for various high-performance applications across multiple industries.

Tags:

Products

MOQ:	150kgs
Price:	Negotiatable
Standard Packaging:	Wood box for Rod
Delivery Period:	2-30days
Payment Method:	,L/C,T/T,Western Union,MoneyGram
Supply Capacity:	300 Ton per Month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

NikTech

Certification

ISO 9001:2008

Model Number

Monel 400

Condition:

Hard / Soft

Melting Range:

1315-1350

Alloys:

Copper Nickel Alloys

Alloy Type:

Nickel-cu-al Alloy

Alloy Or Not:

Is Alloy

Alloy:

Nickel Copper Alloy

Equal Grade:

UNS N05500

Size:

Customized

Electrical Resistivity:

0.615 µΩ·m (at 20°C)

Machinability:

Fair

Type Of Tube:

Straight Tube, U Bend Tube , Coil Tube

Place Of Orig:

China

Modulus Of Elasticity:

200 GPa (29 × 10^6 Psi)

Surface:

Bright,Polished,black

Grade:

UNS N05500/ W.Nr. 2.4375

Minimum Order Quantity:

150kgs

Price:

Negotiatable

Packaging Details:

Wood box for Rod

Delivery Time:

2-30days

Payment Terms:

,L/C,T/T,Western Union,MoneyGram

Supply Ability:

300 Ton per Month

Highlight

Bright nickel copper alloy

N05500 nickel copper alloy

Polished monel k 500

Product Description

Monel K-500 supper nickel copper alloy

Chemical Composition For Monel K500:

Element	Percentage (%)
Nickel (plus Cobalt)	63.0 min
Copper	27.0 - 33.0
Aluminum	2.30 - 3.15
Titanium	0.35 - 0.85
Iron	2.0 max
Manganese	1.5 max
Silicon	0.5 max
Carbon	0.25 max
Sulfur	0.01 max

Physical Properties Of Monel K500

Property	Value
Density	8.44 g/cm³
Melting Range	1315-1350°C
Modulus of Elasticity	179 GPa (tension)
Electrical Resistivity	6.15 μΩ·m at 20°C
Thermal Conductivity	17.2 W/m·K at 20°C

Mechanical Properties Of Monel K500:

Condition	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)	Hardness (HRC)
Hot-Finished, Aged	965 - 1310	690 - 1035	30 - 20	27 - 38
Cold-Drawn, Aged	930 - 1275	655 - 1100	30 - 15	25 - 41

Key Characteristics:

Corrosion Resistance: Monel K-500 exhibits excellent resistance in various marine and chemical environments, from pure water to non-oxidizing mineral acids, salts, and alkalis.
High Strength and Hardness: The alloy maintains high mechanical properties from sub-zero temperatures up to approximately 480°C.
Low Magnetic Permeability: In the age-hardened condition, Monel K-500 has low permeability and is non-magnetic to temperatures as low as -101°C.

Applications:

Monel K-500 is utilized in various industries due to its unique properties:

Marine Engineering: Ideal for chains, cables, springs, and valve components due to its corrosion resistance and high strength.
Oil and Gas Production: Used in pump shafts, impellers, and non-magnetic housings, benefiting from its resistance to sour-gas environments.
Chemical Processing: Suitable for pump and valve components, offering durability in harsh chemical environments.
Aerospace and Defense: Employed in manufacturing turbine blades and gas turbine components operating below 750°C.

Tags:
