405 Monel Alloy Rod High Strength Nickel Copper Alloy For Marine Chemical
  • name

405 Monel Alloy Rod High Strength Nickel Copper Alloy For Marine Chemical

MOQ: 150kgs
Price: Negotiatable
Standard Packaging: Wood Box
Delivery Period: 2-30days
Payment Method: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Capacity: 300 Ton per Month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
NikTech
Certification
ISO 9001:2008
Model Number
Monel 405
Origin:
China
Diameter:
1-500mm
Mean Linear Expansion:
14.2 µm/m•°C
Length:
9000mm
Payment Term:
30%TT+70%TT / LC
Melting Point:
1300-1350°C
Magnetic Properties:
Non-magnetic
Material:
Monel 405
Chemical Position:
Ni 63% Min; Cu 28-34%
Standard:
GB / T 908 -2008 Or As Appropriate
Type:
Bar, Plate, Pipe, Strip, Etc
Applications:
Marine Engineering, Chemical And Hydrocarbon Processing Equipment, Valves, Pumps, Heat Exchangers, Fasteners
Delivery Status:
Sosoloid
Density:
8.80 G/cm3
Wear Resistance:
Excellent
Electrical Resistivity:
0.511µΩ•m
Thermal Conductivity:
22.0 W/m•°C
Highlight:

405 Monel Alloy

,

High Strength Monel Alloy

,

Chemical monel 405

Product Description

Monel 405 Rod: High-Strength Nickel-Copper Alloy for Marine and Chemical Applications

Monel 405 Rod (UNS N04405) is a high-performance nickel-copper alloy designed to provide exceptional corrosion resistance in both fresh and saltwater environments. It offers outstanding resistance to a wide range of corrosive conditions, making it ideal for use in marine, chemical, and other harsh environments. Monel 405 is an alloy known for its durability, strength, and ability to perform well in high-stress conditions.

Monel 405 combines the properties of both nickel and copper, with small amounts of iron, manganese, and silicon, which contribute to its remarkable resistance to corrosion and oxidation. This makes it especially valuable in applications where the material is exposed to sea water or other corrosive chemicals over extended periods of time.

Chemical Composition

Element Composition (%)
Nickel (Ni) 63.0Min
Carbon (C) 0.3Max
Manganese (Mn) 2.0max
Iron (Fe) 2.5 max
Silicon (Si) 0.5 max
Sulfur (S) 0.025-0.06
Copper (Cu) 28.0-34.0

Mechanical Properties

Property Value
Tensile Strength 620 MPa (90 KSI)
Yield Strength (0.2% Offset) 280 MPa (40 KSI)
Elongation 35% min
Hardness 80 – 90 HRB
Impact Energy (at -40°C) 40 J (30 ft-lbf)

Physical Properties

Property Value
Density 8.80 g/cm³
Melting Point 1300 – 1350 °C
Poisson’s Ratio 0.32
Curie Temperature 21-49 ℃

Standards and Specifications

  • UNS: N04405

  • ASTM: B164, B425

  • NACE: MR0175 / ISO 15156

  • ISO: 15156, 2007

Applications

Monel 405 Rod is widely used in a variety of industries due to its corrosion resistance and mechanical strength:

  • Marine Engineering: Its resistance to saltwater corrosion makes it an ideal material for marine applications like propeller shafts, seawater pumps, and boat hulls.

  • Chemical Processing: Monel 405 is used in piping, heat exchangers, and valves that are exposed to aggressive chemicals in industries like petrochemical and pharmaceuticals.

  • Oil and Gas: Ideal for use in equipment exposed to high-pressure environments with corrosive gases and fluids.

  • Aerospace: Commonly found in aircraft components due to its strength and resistance to oxidation at high altitudes.

Frequently Asked Questions (FAQ)

Q1: Why is Monel 405 ideal for marine applications?
A1: Monel 405 offers outstanding resistance to seawater corrosion and is highly resistant to pitting, crevice corrosion, and stress corrosion cracking, making it an excellent choice for marine environments.

Q2: What are the primary applications for Monel 405 Rod?
A2: Monel 405 Rod is used extensively in marine, chemical processing, oil and gas, and aerospace industries, particularly for components exposed to saltwater or aggressive chemicals.

Q3: Can Monel 405 be welded?
A3: Yes, Monel 405 can be welded using common welding techniques such as TIG, MIG, and submerged arc welding. Proper preheating and post-weld treatments may be necessary to prevent cracking.
