0Cr13Al4 Resistance Wire Oxidation Resistance For Industrial Domestic Heating
  • name

0Cr13Al4 Resistance Wire Oxidation Resistance For Industrial Domestic Heating

MOQ: 150kgs
Price: Negotiatable
Standard Packaging: carton, plywood pallet
Delivery Period: 2-30days
Payment Method: L/C,T/T,Western Union
Supply Capacity: 300 Ton per Month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
NikTech
Certification
ISO 9001:2008
Model Number
0Cr13Al4
Electrical Resistivity:
1.0 μΩ·m
Thermal Conductivity:
11.4 W/m·K
Hardness:
200-300 HB
Thermal Expansion Coefficient:
13.5 × 10-6/K
Specific Heat Capacity:
460 J/kg·K
Tensile Strength:
600-800 MPa
Elongation:
20-30%
Coefficient Of Thermal Expansion:
13.5 × 10-6/K
Density:
8.4 G/cm3
Corrosion Resistance:
Excellent
Material:
Nickel-chromium Alloy
Highlight:

0Cr13Al4 Resistance Wire

,

800 MPa Resistance Wire

,

600 MPa nickel chrome resistance wire

Product Description

0Cr13Al4 Resistance Wire – Reliable Oxidation Resistance & Energy Efficiency for Industrial & Domestic Heating



Description

0Cr13Al4 resistance wire is an iron-chromium-aluminum (Fe-Cr-Al) alloy designed for cost-effective heating applications requiring moderate-temperature stability and corrosion resistance. Composed of 12–14% chromium, 3.5–5.0% aluminum, and balanced iron, this alloy forms a protective alumina (Al₂O₃) layer at temperatures up to 1,100°C (2,012°F), ensuring durability in oxidizing and mildly corrosive environments. Its low carbon content (≤0.08%) and controlled silicon (≤1.0%) minimize embrittlement, making it ideal for heating elements in industrial furnaces, household appliances, and automotive systems where operational costs and longevity are critical.

Certified to GB/T 1234 and DIN 17470 standards, the 0Cr13Al4 wire achieves a tensile strength of 450–600 MPa and a surface load capacity of 1.8 W/cm², offering a budget-friendly alternative to nickel-chromium alloys. With a high electrical resistivity (1.25 μΩ·m) and low temperature coefficient of resistance (TCR), it ensures stable energy output in air or dry inert atmospheres, balancing performance and affordability for mid-range thermal applications.



Technical Specifications (Table)

Property Value Standard
Chemical Composition Cr: 12–14%, Al: 3.5–5.0%, Fe: Balance GB/T 1234, DIN 17470
  C: ≤0.08%, Si: ≤1.0%, Mn: ≤0.7% ASTM B603 (similar)
Mechanical Properties Tensile Strength: 450–600 MPa ASTM E8
  Elongation: ≥20%
Physical Parameters Density: 7.3 g/cm³ ISO 6892
  Melting Point: 1,480°C
  Electrical Resistivity: 1.25 μΩ·m



Applications

  1. Industrial Heating: Low-cost heating elements for drying ovens, industrial kilns, and heat treatment equipment.

  2. Consumer Appliances: Toaster coils, electric irons, and space heaters.

  3. Automotive: Seat heaters, defrosting systems, and auxiliary heating units.

  4. Agriculture: Livestock heating panels and greenhouse temperature control systems.

  5. Electrical Systems: Resistors and precision heating components in electronic devices.



Q&A

Q1: What is the maximum continuous operating temperature for 0Cr13Al4 wire?
A: 1,000°C in continuous use and 1,100°C for short-term operations, ideal for applications below severe thermal stress.

Q2: Can this alloy resist sulfur-containing atmospheres?
A: Limited resistance. For sulfur-rich environments above 600°C, consider higher-grade Fe-Cr-Al alloys like 0Cr21Al6.

Q3: Is pre-oxidation treatment necessary for new heating elements?
A: Recommended. Heat-treat at 850–950°C for 1–2 hours to enhance the protective alumina layer and extend lifespan.
