0.3mm-3mm Incoloy 825 Plate Solid Solution Alloy Marine And Chemical Service

Products

0.3mm-3mm Incoloy 825 Plate Solid Solution Alloy Marine And Chemical Service

MOQ:	150kgs
Price:	Negotiatable
Standard Packaging:	Wooden Crate
Delivery Period:	2-30days
Payment Method:	L/C,T/T,Western Union,MoneyGram
Supply Capacity:	300 Ton per Month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

NikTech

Certification

ISO 9001:2008

Model Number

Incoloy 825

Place Of Origin:

China

Machinability:

Equal Grades:

NS1402(China)

Standard:

ASTM,ASME,ASTM/JIS/DIN/GB

Magnetic Permeability:

1.04-1.07

Alloy Type:

Iron Nickel Based Alloy

Nickel:

30.0-35.0

Surface:

2B,BA,NO.1,8K,HL,polished

Application:

Chemical Processing

Testing Facility:

Accept Third Party Testing Such As SGS

Service:

OEM\ODM

Alloys:

Incoloy Alloys

Specification:

0.3mm-3mm

Temperature Range:

-253-982°C

Highlight:

3mm incoloy 825 plate

0.3mm incoloy 825 plate

Marine alloy 825 plate

Product Description

Incoloy 825 Plates: Solid-Solution Alloy and Marine and Chemical Service

Product Overview

Incoloy 825 Plates are wrought, nickel-iron-chromium-molybdenum-copper-titanium alloys designed to withstand continuous exposures up to 816 °C (1500 °F) and intermittent 982 °C (1800 °F) while resisting oxidation, carburization, and chloride stress-corrosion cracking. Their solid-solution strengthening—driven by 2.5–3.5 % molybdenum and 1.5–3 % copper—avoids precipitation aging and stabilizes mechanical properties from cryogenic service to high temperatures, delivering tensile strengths ≥ 760 MPa and elongations ≥ 30 % in the annealed condition. Chromium levels of 19.5–23.5 % and titanium additions form protective chromia and alumina scales, conferring resistance to nitric, sulfuric, and phosphoric acids, as well as to oxidative salt atmospheres . These plates are specified in ASTM B424/B424M for plate and sheet; AMS 5599; and meet ISO 15156-3/NACE MR0175 sour-service requirements, making them indispensable for acid production, oil & gas well piping, and nuclear fuel reprocessing equipment. Exceptional formability and weldability (TIG/GTAW, electron-beam) support complex panel fabrication, reducing assembly time and maximizing reliability across South Asia, Southeast Asia, the Middle East, Europe, and the Americas.

Chemical Composition

Element	Content (%)
Nickel (Ni)	38.0 – 46.0
Iron (Fe)	21.0 – 28.0
Chromium (Cr)	19.5 – 23.5
Molybdenum (Mo)	2.50 – 3.50
Copper (Cu)	1.50 – 3.00
Titanium (Ti)	0.60 – 1.20
Aluminum (Al)	0.20 – 0.80
Manganese (Mn)	≤ 1.00
Silicon (Si)	≤ 0.50
Carbon (C)	≤ 0.050
Sulfur (S)	≤ 0.030

Mechanical Properties

Property	Value
Ultimate Tensile Strength	≥ 760 MPa (110 ksi)
Yield Strength (0.2 % offset)	≥ 310 MPa (45 ksi)
Elongation (4 D)	≥ 30 %
Hardness (Rockwell B)	≤ 95 HRB

Physical Properties

Property	Value
Density	8.00 g/cm³
Melting Range	1425 – 1455 °C
Thermal Conductivity (25 °C)	11.2 W/m·K
Specific Heat Capacity (25 °C)	435 J/kg·K
Coefficient of Thermal Expansion (20–100 °C)	14.4 µm/m·°C
Electrical Resistivity (20 °C)	0.77 µΩ·m

Conformance Standards

ASTM B424 / ASME SB-424 – Plate, sheet, and strip form
ASTM B425 / ASME SB-425 – Strip and foil form
AMS 5599 – Special-quality strip/sheet
ISO 15156-3 / NACE MR0175 – Sour-service compatibility

Applications

Chemical Processing: Heat-exchanger panels, reactor liners, pollution-control scrubbers
Oil & Gas: Well-piping panels, acid-production vessels, corrosion-resistant cladding
Marine & Offshore: Seawater condenser panels, subsea manifold liners
Power Generation: Gas-turbine ducting, combustion-chamber panels
Nuclear: Fuel-reprocessing equipment, radioactive-waste handling trays

Frequently Asked Questions

Q1: Why choose Incoloy 825 Plates for corrosive environments?
A1: High molybdenum and copper enhance resistance to reducing acids (sulfuric, phosphoric), while chromium and nickel protect against oxidizing media and chloride stress-corrosion cracking.

Q2: Can Incoloy 825 Plates be welded without sensitization?
A2: Yes—titanium additions stabilize against intergranular attack, and TIG/GTAW or EB welding followed by minimal heat treatment preserves alloy integrity.

Q3: What is the maximum service temperature?
A3: Continuous service up to 816 °C (1500 °F), intermittent to 982 °C (1800 °F), with stable mechanical and corrosion performance across this range.
