Inconel 617 Strips: Creep-Resistant Alloy for Sour-Service and Heat-Treatment

Products

Inconel 617 Strips: Creep-Resistant Alloy for Sour-Service and Heat-Treatment

MOQ:	150kgs
Price:	Negotiatable
Standard Packaging:	Wooden Crate
Delivery Period:	2-30days
Payment Method:	L/C,T/T,Western Union,MoneyGram
Supply Capacity:	300 Ton per Month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

NikTech

Certification

ISO 9001:2008

Model Number

Inconel 617

Place Of Origin:

China

Melting Point:

1300-1350°C

Elongation At Break:

35-60% (Annealed)

Corrosion Resistance:

Excellent

Business Type:

Manufaturer

Density:

8.80 G/cm3

Machinability:

Outer Diameter:

6-2500mm, (3/8"-100")

Diameter:

0.02 - 1 Mm, 1-3 Mm, 5-7 Mm

Technique:

Cold-rolled

Executive Standard:

Form:

MIG(15kg/spool), TIG(5kg/box),Strip

Type Of Tube:

Straight Tube, U Bend Tube , Coil Tube

Packing:

Standard Export Packing

Highlight:

astm inconel alloy

tube inconel alloy

astm inconel 601 wire

Product Description

Inconel 617 Strips: Creep-Resistant Alloy for Sour-Service and Heat-Treatment

Product Overview

Inconel 617 Strips (UNS N06617) are solid-solution-strengthened nickel-chromium-cobalt-molybdenum alloys designed for continuous service from cryogenic temperatures up to 982 °C (1800 °F). The alloy’s balanced chemistry—approximately 52 % Ni, 22 % Cr, 12.5 % Co, 9.5 % Mo, 1.2 % Al, and minor Ti—provides outstanding resistance to oxidation, carburization, and high-temperature corrosion in both oxidizing and reducing atmospheres. Inconel 617 maintains tensile strength above 760 MPa and elongation of 30 % after solution annealing, with no loss of ductility after extended thermal exposure. Its exceptional resistance to chlorides, superheated steam, and high-purity water makes it the material of choice for heavy-duty furnace components, gas-turbine transition ducts, and heat-treating baskets. The alloy is readily formed by stamping, bending, and fine blanking, and welds cleanly via TIG/GTAW or electron-beam processes, retaining full mechanical properties post-weld. Available in thicknesses from 0.05 mm to 5 mm and widths up to 300 mm, Inconel 617 Strips meet stringent ASTM B166/B168 and AMS 5520 standards for strip and foil form.

Chemical Composition

Element	Content (%)
Nickel (Ni)	50.0 – 55.0
Chromium (Cr)	20.0 – 24.0
Cobalt (Co)	12.0 – 15.0
Molybdenum (Mo)	8.0 – 10.0
Aluminum (Al)	0.4 – 1.0
Titanium (Ti)	0.2 – 0.6
Iron (Fe)	Balance
Carbon (C)	≤ 0.10
Manganese (Mn)	≤ 1.0
Silicon (Si)	≤ 0.5
Sulfur (S)	≤ 0.015
Phosphorus (P)	≤ 0.015

Mechanical Properties

Condition	Tensile Strength	Yield Strength (0.2 % off.)	Elongation (4 D)	Hardness
Annealed (982 °C max)	≥ 760 MPa	≥ 310 MPa	≥ 30 %	≤ 95 HRB

Physical Properties

Property	Value
Density	8.19 g/cm³
Melting Range	1250 – 1350 °C
Thermal Conductivity (25 °C)	11.1 W/m·K
Specific Heat (25 °C)	435 J/kg·K
Coefficient of Thermal Expansion	13.0 µm/m·°C (20–100 °C)
Electrical Resistivity (20 °C)	1.27 µΩ·m
Magnetic Permeability	≈ 1.002 (non-magnetic)

Conformance Standards

ASTM B166 / B168 – Cold-rolled strip and foil
AMS 5520 – Strip and foil form
ISO 15156-3 / NACE MR0175-3 – Sour-service compatibility
UNS N06617 / W. Nr. 2.4663 – Material designation

Applications

Aerospace & Power Generation: Turbine transition ducts, combustion liners, generator brushes
Heat Treatment & Furnaces: Basket supports, retort liners, radiant tubes
Chemical & Petrochemical: Reactor coils, heat-exchanger fins, piping gaskets
Marine & Offshore: Subsea flow-lines, condenser plates, valve components
Nuclear: Control-rod springs, spacer grids, fuel-element wrappers

Frequently Asked Questions

Q1: Why select Inconel 617 Strips for high-temperature service?
A1: Their solid-solution strengthening sustains mechanical integrity up to 982 °C without aging treatments, plus superior oxidation and corrosion resistance in diverse atmospheres.

Q2: Are Inconel 617 Strips weldable and formable?
A2: Yes. They weld readily by TIG/GTAW or electron-beam and form easily via stamping, bending, and fine blanking, retaining full mechanical properties post-weld.

Q3: What strip dimensions and conditions are available?
A3: Standard thicknesses range from 0.05 mm to 5 mm, widths up to 300 mm; available in mill-annealed or stress-relieved conditions per ASTM B166/B168 and AMS 5520.
