2.4617 Hastelloy Alloy Hastelloy B2 Rod For Acidic Chemical Applications

Products

2.4617 Hastelloy Alloy Hastelloy B2 Rod For Acidic Chemical Applications

MOQ:	150kgs
Price:	Negotiatable
Standard Packaging:	Woodbox
Delivery Period:	2-30days
Payment Method:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Capacity:	300 Ton per Month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

NikTech

Certification

ISO 9001:2008

Model Number

Hastelloy B2

Corrosion Resistance:

Excellent

Model:

Hastelloy B2

Elastic Modulus:

179GPa

Brand No:

NicTech

Shape:

Surface:

Bright

Melting Range:

1427°C

Technique:

Cold-rolled

Powder Or Not:

Not Powder

Tensile Strength:

914 MPa 133000 Psi

Yield Strength (@strain 0.200%):

396 MPa 57400 Psi

Elastic Modulus:

217 GPa 31500 Ksi

Elongation At Break (in 50.8 Mm):

Hardness, Brinell (converted From Rockwell B Hardness):

Hardness, Rockwell B:

Properties Metric Imperial Thermal Expansion Co-efficient (@21-100°C/69.8-212°F):

10.3 µm/m°C

Thermal Conductivity:

11.1 W/mK

Standar:

UNS N10665

Common Name:

W. Nr./EN 2.4617， DIN 2.4615，Alloy B2

Highlight:

2.4617 Hastelloy Alloy

B2 Hastelloy Alloy

Cold rolled hastelloy b2

Product Description

2.4617 Hastelloy B2 Rod – Ideal Material for Acidic Chemical Applications

Hastelloy B2 (UNS N10665, Werkstoff No. 2.4617) is a high-performance nickel-molybdenum alloy renowned for its exceptional resistance to reducing acids, including hydrochloric, sulfuric, acetic, and phosphoric acids. Its unique composition and microstructure make it an ideal choice for critical applications in chemical processing, pharmaceutical manufacturing, and petrochemical industries.

Chemical Composition

Element	Composition (%)
Nickel (Ni)	Balance
Molybdenum (Mo)	26.0–30.0
Iron (Fe)	Max 2.0
Chromium (Cr)	Max 1.0
Carbon (C)	Max 0.02
Manganese (Mn)	Max 1.0
Silicon (Si)	Max 0.10
Cobalt (Co)	Max 1.0
Phosphorus (P)	Max 0.04
Sulfur (S)	Max 0.03

Mechanical Properties

Property	Value
Density	9.22 g/cm³
Melting Point	1330–1380°C
Tensile Strength	Min 760 MPa (110 ksi)
Yield Strength	Min 350 MPa (51 ksi)
Elongation	Min 40%

Physical Properties

Property	Value
Elastic Modulus	179GPa
Thermal Conductivity	17.3W/m·K at room temperature
Coefficient of Thermal Expansion	11.7 μm/m·°C (20–93°C)

ASTM Specifications

Form	ASTM Standard
Bar	ASTM B335
Sheet/Plate	ASTM B333
Pipe (Seamless)	ASTM B622
Pipe (Welded)	ASTM B619
Tube (Seamless)	ASTM B622
Tube (Welded)	ASTM B626
Forging	ASTM B564
Fitting	ASTM B366

Applications

Hastelloy B2 Rod is extensively used in:

Chemical reactors and heat exchangers
Piping systems handling hydrochloric acid
Pharmaceutical manufacturing equipment
Pollution control systems
Pickling and acid cleaning operations

Corrosion Resistance

Hastelloy B2 exhibits:

Outstanding resistance to hydrochloric acid at all concentrations and temperatures
Excellent resistance to sulfuric, acetic, and phosphoric acids
Superior resistance to hydrogen chloride gas
Exceptional resistance to pitting, stress corrosion cracking, and crevice corrosion
Resistance to knife-line and weld heat-affected zone attack

However, it should not be used in oxidizing environments or where oxidizing contaminants are present in reducing media, as this can lead to rapid corrosion and premature failure.

FAQs

1. What is Hastelloy B2?

Hastelloy B2 is a nickel-molybdenum alloy designed for exceptional resistance to reducing acids and aggressive chemical environments.

2. What are the mechanical properties of Hastelloy B2?

Hastelloy B2 offers high tensile strength (min 760 MPa), yield strength (min 350 MPa), and elongation (min 40%), making it suitable for demanding applications.

3. What industries use Hastelloy B2 Rod?

Industries such as chemical processing, pharmaceuticals, petrochemicals, and pollution control utilize Hastelloy B2 Rod for its superior corrosion resistance.
