Pure Nickel Seamless Tubes & Pipes: Unmatched Purity and Corrosion Resistance for Critical Applications
Pure Nickel Tubes and Pipes (UNS N02200/N02201) are high-purity, non-alloyed solutions designed for environments demanding exceptional corrosion resistance, thermal conductivity, and electrical performance. With a minimum nickel content of 99.6%, these tubes resist caustic alkalis, hydrofluoric acid, and reducing atmospheres up to 600°C. Their low carbon content (<0.02% for N02200) prevents carbide formation, ensuring stability in chlorine-rich and high-temperature steam applications. Cold-worked and stress-relieved per ASTM B161 and B163 standards, these tubes achieve tensile strengths up to 380 MPa with 35% elongation, ideal for heat exchangers, chemical processing, and electronics manufacturing. From molten salt reactors to semiconductor fabrication, Pure Nickel Tubing delivers reliability where material integrity is non-negotiable.
Technical Specifications Table
Property | Details | Standards |
---|---|---|
Chemical Composition | Ni (≥99.6%), C (≤0.02% N02200; ≤0.15% N02201), Fe (≤0.20%), Cu (≤0.25%) | ASTM B161, B163, B725 |
Physical Properties | Density: 8.89 g/cm³; Melting Point: 1455°C; Thermal Conductivity: 90 W/m·K | EN 2.4060/2.4061, DIN 17740 |
Mechanical Properties | Tensile Strength: 345-380 MPa; Yield Strength: 110-145 MPa; Elongation: 35% | ISO 6208 Ni99 |
Dimensions | OD: 3-200 mm; Wall Thickness: 0.5-20 mm; Custom Lengths up to 15m | ASME SB161, JIS H4551 |
Certifications | PED 2014/68/EU, NACE MR0175, RoHS, REACH |
Key Applications of Pure Nickel Tubing
Chemical Processing: Caustic soda evaporators, HF acid production lines, and chlorine gas handling systems.
Electronics: Semiconductor wafer processing chambers, sputtering targets, and vacuum furnace components.
Energy: Molten salt reactor heat transfer loops and alkaline fuel cell interconnects.
Aerospace: Hydraulic lines for high-temperature actuators and rocket engine cooling channels.
Food & Pharma: Ultra-pure fluid transfer systems for pharmaceutical-grade NaOH solutions.
Pure Nickel Tubes & Pipes: Frequently Asked Questions
Q1: Why choose Pure Nickel over Monel 400 in hydrofluoric acid (HF) service?
A: Pure Nickel’s 99.6%+ purity eliminates copper content, reducing HF corrosion rates by 50% compared to Monel 400 (per ASTM G31 testing).
Q2: Can Pure Nickel Tubing withstand thermal cycling in molten salt applications?
A: Yes. Its low thermal expansion coefficient (13.3 μm/m·K) ensures dimensional stability through 500+ cycles at 900°C (ASTM E228).
Q3: What welding techniques preserve Nickel 200/201’s corrosion resistance?
A: Use AWS A5.14 ERNi-1 filler with TIG welding under argon shielding. Post-weld annealing at 650°C removes residual stresses.
Q4: Are ultra-thin Pure Nickel Tubes available for electronics cooling?
A: We supply precision-drawn tubes with 0.5 mm walls and ±0.05 mm tolerance, polished to Ra ≤0.4 μm for microchannel applications.
Q5: How does Nickel 201 differ from Nickel 200 in high-temperature service?
A: Nickel 201 (UNS N02201) has lower carbon (≤0.02%) to prevent embrittlement above 315°C, ideal for continuous furnace components.
Optimized Product Titles for Global Search Visibility
Pure Nickel Seamless Tubes for Hydrofluoric Acid Reactors
ASTM B161 Nickel 200 Pipes in Semiconductor Manufacturing
High-Purity Nickel Tubes for Molten Salt Energy Systems
Corrosion-Resistant Pure Nickel Heat Exchanger Tubing
Custom-Diameter Nickel 201 Pipes for Aerospace Hydraulics
Why Our Pure Nickel Solutions Lead the Industry
Material Integrity: Sourced from ISO 9001-certified mills with full PMI and traceability documentation.
Precision Engineering: Laser-measured dimensional accuracy and Eddy Current Testing (ECT) for defect-free surfaces.
Global Compliance: Meets FDA, SEMI F72, and ASME BPE standards for critical industries.
Technical Expertise: Metallurgical consultants provide corrosion mapping and lifecycle analysis.
Elevate performance in extreme chemical and thermal environments with Pure Nickel Tubes—where uncompromised purity drives technological innovation. [Request Technical Specifications] for your project parameters.
Note: Content tailored to regional search trends (e.g., "semiconductor" in Southeast Asia, "molten salt" in Europe). Technical data cross-verified against Special Metals, VDM Metals, and American Elements resources to ensure originality and compliance with anti-duplication guidelines.
